APC/Schneider Electric Rack PDU PN AP7900B

$1,255.00

Ideal for colocation, large data center, or remote edge computing

On/off outlet switching enable users to reboot connected equipment remotely

Plan capacity & balance loads with +/- 5% metering accuracy (amps)

Enables improved energy efficiency and scope 1 and 3 emissions tracking

Easily monitor, control and manage through EcoStruxure IT & other platforms

Rack PDU, Switched, 1U, 15A, 100/120V,

SKU: AP7900B Category: APC Power Distribution Units Brand: APC/Schneider Electric

Description

APC/Schneider Electric Rack PDU PN AP7900B

Name: APC/Schneider Electric Rack PDU PN AP7900B
Brand: APC/Schneider Electric
SKU: AP7900B
Availability: InStock

APC NetShelter Switched Rack PDU, 1U, 1.4kW, 120V, 15A, 8 NEMA 5-15R outlet

APC/Schneider Electric Rack PDU PN AP7900B has a wide range of standardized PDU features that increase network efficiency, manageability and functionality. The output and input connections are (8)5-15. Network management capabilities allow you to configure and manage rack PDUs from remote locations. It has has a local current monitoring display that gives a visible warning in case of an overload. The remote individual outlet control provides real-time monitoring of connected loads. It has a multi-tier user access that enables you to restrict unauthorized use of outlets. This rack has a single input power source making it easy to install.

Specifications

Overview
Presentation	This APC Switched Rack PDU power distribution unit has a wide range of standardized PDU features that increase network efficiency, manageability and functionality. The output and input connections are (8)5-15. Network management capabilities allow you to configure and manage rack PDUs from remote locations. It has has a local current monitoring display that gives a visible warning in case of an overload. The remote individual outlet control provides real-time monitoring of connected loads. It has a multi-tier user access that enables you to restrict unauthorized use of outlets. This rack has a single input power source making it easy to install.
Lead time	Usually in Stock

Main
Color	Black
Product or Component Type	PDU
PDU Type	Switched
Cord length	11.98 ft (3.65 m)
Number of cables	1
Provided Equipment	Cord retention bracket(s) Horizontal mounting brackets User Manual Installation guide

Complementary
Input Voltage	100 V 120 V
Height	1.7 in (44 mm)
Width	17.5 in (445 mm)
Output Voltage	120 V
Depth	4.3 in (108 mm)
Net Weight	5.004 lb(US) (2.27 kg)
Mounting Location	Front Rear
Mounting preference	No preference
Input Plug Type	NEMA 5-15P
Mounting Mode	Rack-mounted
Rack units	1U
Mounting position	Horizontal
Line Rated Current	12 A
Acceptable Input Voltage	100…120 V
Input current limits	15 A
Load Capacity	1440 VA
Input Frequency	50/60 Hz
Outlet type and quantity	8 NEMA 5-15R

Environment
Product Certifications	cUL Listed UL Listed
Standards	FCC Part 15 class A ICES-003
Ambient air temperature for operation	32…113 °F (0…45 °C)
Relative Humidity	0…95 %
Operating altitude	0…10000 ft
Ambient Air Temperature for Storage	-13…149 °F (-25…65 °C)
Storage Relative Humidity	0…95 %
Storage altitude	0…50000 ft (0…15240 m)

Ordering and shipping details
Category	80230-IG SEBA TO SEUSA
Discount Schedule	BMS1
GTIN	731304331568
Returnability	No
Country of origin	PH

Packing Units
Unit Type of Package 1	PCE
Nbr. of units in pkg.	1
Package 1 Height	2.8 in (7 cm)
Package 1 Width	13.5 in (34.3 cm)
Package 1 Length	18.5 in (47 cm)
Package weight(Lbs)	7.61 lb(US) (3.45 kg)

Contractual warranty
Warranty	2 years repair or replace

Specs

Videos

Additional information

Weight	8.15 lbs
Dimensions	13.6 × 19.8 × 2.8 in
