Micro Touch LCD Touch Screen Monitor Display PN DT-100P-A1

$341.55

Specifications

Touch LCD Display

Touch Screen: Projected Capacitive
Touch Points: 10
Touch Screen Interface: USB-HID
Display Surface: 7H Hardness durable glass

I/O Ports

OSD Port: 1 x RJ11
USB Port: 1 x USB Type C (ALT Mode & PD Input)
Video Port: 1 x VGA, 1 x DP, 1 x HDMI
Audio Port: 1 x Audio-Input (3.5 mm Mini-Jack)
Power Input: 1 x DC In 12V Jack Power Input

Physical Properties

Power Supply: 36W (12V, 3A) External Power Adaptor
Speaker: 2 x 2W Stereo
Housing Color: Black
Material: Plastic, Glass, SECC Metal
Dimensions (W x H x D) mm: 245.4 x 170.5 x 30.3 mm (monitor only)
Net Weight (kg): 0.95 kg (monitor only)
Gross Weight (kg): 6.80 kg (5 units set) (monitor only)
Carton (W x H x D) mm: 450 x 335 x 295 mm (monitor only)
VESA: 75 x 75 mm

Safety

Certifications: CE, FCC, UL, CB, UKCA

Environment

Operating Temperature: 0˚C ~ 40˚C, 20% ~ 80% RH. Non-Condensing
Storage Temperature: -20˚C ~ 60˚C, 10% ~ 90% RH. Non-Condensing

Box Contents/What’s in the Box

LCD Touch Monitor, Power Cord, Power Supply, AC-DC Adapter, HDMI, USB-C to A, USB-C to C

DT-100P-A1

Category: Desktop Touch Screen Brand: Micro Touch

Description

Micro Touch LCD Touch Screen Monitor Display PN DT-100P-A1

Name: Micro Touch LCD Touch Screen Monitor Display PN DT-100P-A1
Brand: Micro Touch
SKU: 12402
Availability: InStock

MICROTOUCH, 10.1″ DESKTOP, 1280×800, VGA/HDMI/DP/USB-C, 10 TOUCH POINTS, PCAP, 350NITS, NO STAND, 75×75 mm VESA COMPATIBLE, 3 YEAR WARRANTY

Micro Touch LCD Touch Screen Monitor Display PN DT-100P-A1 is a one-stop-shop solution for a variety of applications. The versatile USB-C port with ALT DP mode, power delivery input, and touch acceptance eliminates the need to manage multiple cables enabling a seamless aesthetic while driving efficiencies during the installation process. This 10-point touch projected capacitive display with a 16:10 – 1280×800 resolution is designed to create a memorable touch experience for retail point-of-sale second displays, small form factor point-of-service, in-aisle or end-aisle interactive signage applications, and more. The seamless bezel, advanced PCAP technology and rounded aesthetic bridges the gap between daily consumer devices and commercial devices, a step towards commonality and memorable end-user experience.

Featured Specifications

Size: 10.1″ TFT LCD
Maximum Resolution: 1280 x 800
Contrast Ratio: 1000:1
Aspect Ratio: 16:10
Brightness: 350 nits (No Touch), 290 nits (PCAP)
View Angle: H:160˚, V:160˚
Video Port: 1 x VGA, 1 x DP, 1 x HDMI
Warranty: 3 year

Videos

Resources

Additional information

Dimensions	11.614173 × 17.716535 × 13.188976 in
