Elo 1504L 15in Touchscreen Monitor PN E969493

Elo 1504L 15in Touchscreen Monitor PN E969493 is a commercial-grade touchscreen display designed for point-of-sale systems, customer-facing applications, self-service, retail, hospitality, industrial controls, interactive workstations, and other demanding commercial environments. Featuring a 15.6-inch active-matrix TFT LCD with native 1920 × 1080 Full HD resolution and a 16:9 aspect ratio, the 1504L delivers sharp, detailed visuals in a versatile widescreen format. Elo’s TouchPro® Projected Capacitive (PCAP) technology supports up to 10 simultaneous touch points, providing fast and responsive multi-touch interaction for modern commercial applications. PN E969493 is the configuration supplied with the desktop stand, providing a complete countertop touchscreen solution ready for deployment.

Designed for excellent image quality and visibility, the Elo 1504L E969493 features 450 nits typical LCD panel brightness, 405 nits with the PCAP touch layer, a 1000:1 contrast ratio, and wide 178-degree horizontal and vertical viewing angles. The anti-glare surface helps reduce reflections in brightly lit retail, restaurant, office, and industrial environments, while support for 16.7 million colors provides clear and vibrant on-screen content. The monitor also includes Low Blue Light settings for improved viewing comfort during extended use.

The Elo 1504L offers extensive connectivity for integration with modern and legacy commercial systems. Available interfaces include USB Type-C, USB Type-A, DisplayPort, HDMI, a DC power input, and four Micro-USB Elo Edge Connect ports for compatible Elo peripherals. USB Type-C supports compatible power-delivery configurations, while HDMI and DisplayPort provide flexible video connectivity. The monitor also includes dual integrated 2-watt speakers, making it suitable for applications requiring audio without separate external speakers.

Built for demanding commercial deployments, the Elo 1504L features IP54 ingress protection and IK08 impact protection, helping it withstand the challenges of high-traffic business environments. The display supports both 75 × 75 mm and 100 × 100 mm VESA mounting, allowing businesses to move beyond the included stand and install the monitor on compatible wall mounts, poles, arms, kiosks, and custom mounting systems. Elo rates the monitor for a demonstrated 50,000-hour MTBF, and the product is backed by a 3-year standard warranty.

Whether you’re building a point-of-sale workstation, customer-facing display, self-service system, restaurant terminal, interactive business application, or industrial control interface, the Elo 1504L PN E969493 delivers the commercial durability, connectivity, and responsive touch experience expected from Elo. Its 15.6-inch Full HD display, 10-touch PCAP technology, 450-nit panel brightness, USB-C, HDMI and DisplayPort connectivity, integrated speakers, IP54 and IK08 protection, flexible VESA mounting, and included desktop stand make it a versatile touchscreen solution for modern commercial deployments.

Elo 1504L 15.6-inch Wide LCD Desktop, Full HD 1920 x 1080, Projected Capacitive 10-touch, USB Controller, Anti-glare, Zero-bezel, Stand, USB-A, USB-C, HDMI and DP Inputs, Black, Worldwide
