Description
APC/Schneider Electric Smart-UPS X 2200VA Rack/TowerLCD 200-240 PN SMX2200RMHV2U
APC Smart-UPS X, Line Interactive, 2200VA, Rack/tower convertible 2U, 208V-230V, 8x C13+1x C19 IEC, SmartSlot, Extended runtime
APC Smart-UPS X 2200VA Rack/Tower LCD 200-240V
APC/Schneider Electric Smart-UPS X 2200VA Rack/TowerLCD 200-240 PN SMX2200RMHV2U is designed for IT managers or network administrators to maintain business uptime, data transfer and continuity during prolonged power outages. The 2200VA line interactive 2U rack/tower UPS provides pure sine wave power to support critical electronics during power disruptions. The SMX comes with IEC 320 C20 input (includes BS1363A, IEC 320 C20 and Schuko CEE 7/EU1-16P power cords), 8x IEC 320 C13 and 1x IEC 320 C19 outlets. The UPS has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. This uninterrupted power supply can connect to EcoStruxure IT or third-party centralized management platforms. The SMX UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. This is compatible with dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications. The Smart-UPS comes with a pair of tower-mounting stabilizing feet and rack-mounting brackets. The 3 switchable outlet groups allow more granular management of the power supplied to your devices. The Emergency Power Off feature enables the UPS to remotely shutdown during emergencies.
Specifications
Overview
| Presentation |
Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices. |
| Lead time |
Usually in Stock |
Main
|
|
|
|
|
|
| Product or Component Type |
Uninterruptible power supply (UPS) |
Complementary
| Communication port type |
SmartSlot |
| Mounting mode |
Rack-mounted with included kit |
| UPS connectivity |
Serial port
USB port
Available expansion slot |
| Battery Size |
Lead-acid internal included |
Batteries & Runtime
| Run Time |
View Runtime Graph |
| Efficiency |
View Efficiency Graph |
| Battery Type |
Lead-Acid battery |
| Extendable Run Time |
1 |
| Included Battery Modules |
0 |
| Battery Slots Empty |
0 |
| Typical recharge time |
3 h |
| RBC Quantity |
1 |
| Battery life |
3…5 year(s) |
| Replacement battery |
APCRBC117
|
| Battery Charge Power (Watts) |
233 W rated |
General
| Provided equipment |
CD with software
Documentation CD
Smart UPS signalling RS-232 cable
User Manual
USB cable
Rack Mounting brackets |
| Number of power module |
0 |
| Number of power module filled slots |
0 |
| Number of power module free slots |
0 |
| product web sub-family |
Extended run |
| Redundant |
No |
Physical
| Number of rack unit |
2U |
| Cable length |
6 ft (1.8 m) |
| Number of cables |
1 |
| color |
Black |
| Height |
3.3 in (85 mm) |
| Width |
17.008 in (432 mm) |
| Depth |
26.3 in (667 mm) |
| Net Weight |
82.28 lb(US) (37.32 kg) |
| Mounting Location |
Front |
| Mounting preference |
Lower |
| Mounting Mode |
Rack-mounted |
| Two post mountable |
0 |
| USB compatible |
Yes |
Input
| Main Input Voltage |
208 V AC
230 V AC |
| Other Input Voltage |
220 V
240 V |
| Input Connection Type |
IEC 320 C20
Schuko CEE 7 / EU1-16P
BS1363A British |
| Efficiency at full load |
140…280 V |
| Input Frequency |
50/60 Hz +/- 3 Hz auto-sensing |
Output
| Main Output Voltage |
208 V AC 1 phase
230 V AC 1 phase |
| Other Output Voltage |
220 V
240 V |
| Kw Rating |
1980 W |
| Rated power in VA |
2200 VA |
| output connection type |
8 IEC 320 C13
2 IEC Jumpers
1 IEC 320 C19 |
| Harmonic distortion |
Less than 5% |
| Maximum configurable power in VA |
2200 VA |
| Max Configurable Power (Watts) |
1980 W |
| Transfer Time |
2-4 ms
6ms typical : 10ms maximum |
| Topology |
Line Interactive |
| Waveform Type |
Sine wave |
| Output frequency |
50/60 Hz +/- 3 Hz sync to mains |
Conformance
| Product Certifications |
CE
EAC
IRAM
RCM
TISI
VDE
UK PSTI |
| Standards |
EN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018 |
Environmental
| Acoustic level |
55 dBA |
| Heat dissipation |
150 Btu/h |
| Operating altitude |
0…10000 ft |
| Ambient air temperature for operation |
32…104 °F (0…40 °C) |
| Ambient Air Temperature for Storage |
5…113 °F (-15…45 °C) |
| Storage altitude |
0…50000 ft (0…15240 m) |
| Relative Humidity |
0…95 % |
| Storage Relative Humidity |
0…95 % |
Communications & Management
| Control panel |
LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators
Multi-function LCD status and control console |
| Emergency Power Off (EPO) |
Yes |
| Free slots |
1 |
| Alarm |
Alarm when on battery : distinctive low battery alarm : configurable delays |
Surge Protection and Filtering
| Surge energy rating |
645 J |
| Filtering |
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : m |
Ordering and shipping details
| GTIN |
731304272687 |
| Country of origin |
PH |
Packing Units
| Unit Type of Package 1 |
PCE |
| Nbr. of units in pkg. |
1 |
| Package 1 Height |
9.843 in (25.000 cm) |
| Package 1 Width |
23.622 in (60.000 cm) |
| Package 1 Length |
34.252 in (87.000 cm) |
| Package weight(Lbs) |
104.367 lb(US) (47.340 kg) |
| Unit Type of Package 2 |
P12 |
| Number of Units in Package 2 |
2 |
| Package 2 Height |
29.528 in (75.000 cm) |
| Package 2 Width |
31.496 in (80.000 cm) |
| Package 2 Length |
47.244 in (120.000 cm) |
| Package 2 Weight |
235.189 lb(US) (106.680 kg) |
| Pallet unit layers |
2 |
| Pallet layers |
4 |
Contractual warranty
| Warranty |
3 years repair or replace (excluding battery) and 2 years for battery, optional on-site warranties available, optional extended warranties available |
