APC/Schneider Electric Rack PDU 2G PN AP8867

$4,285.00

Ideal for colocation, large data centers or distributed IT sites

Plan capacity and balance loads with +/- 3% metering accuracy (amps, volts, kW, kWh)

Real-time remote monitoring of connected load through EcoStruxureTM IT and other platforms

Stay on top by defining alarm thresholds in order to avoid overloaded circuits

Zero U toolless installation

Rack PDU 2G,Metered,ZeroU, 17.2kW, 208V,

SKU: AP8867 Category: APC Power Distribution Units Brand: APC/Schneider Electric

Description

APC/Schneider Electric Rack PDU 2G PN AP8867

Name: APC/Schneider Electric Rack PDU 2G PN AP8867
Brand: APC/Schneider Electric
SKU: AP8867
Availability: InStock

APC NetShelter Metered Rack PDU, 0U, 17.3kW, 208V, 3 phase, 60A, 30 C13 outlets

APC/Schneider Electric Rack PDU 2G PN AP8867 distributes reliable power within a rack through a single input and multiple output receptacles The AP8867 offers real-time remote monitoring of connected loads and user-defined alarms to help prevent circuit overloads that can cause accidental power loss to critical equipment The 0U PDU includes a IEC 60309 60A 3P + PE input plug with 1 83m (6ft) cord and (30) IEC 60320 C13 output receptacles The PDU can operate in a maximum ambient air temperature of up to 60°C (140°F) at full load The Network Management Card provides enhanced cybersecurity with secured interfaces and modified password policy The rack PDU integrates with EcoStruxureTM IT through a Network Management Card and can be accessed and configured via Web, SNMP, and Command Line Interface User-interactive LCD interface details current, real power, voltage, and energy measurements for local user access Embedded log memory with historical reporting enables users to meter power usage, optimize energy usage, and plan for capacity The PDU’s locking IEC outlets, when used with locking power cords reduce the probability of accidentally disconnecting cords and dropping loads The rack PDU supports daisy-chaining of up to 4 PDUs on a single IP address An environmental monitoring port is available for external temperature/humidity monitoring (sensor sold separately, model AP9335T or AP9335TH) The rack PDU comes with a standard two-year warranty.

Specifications

Overview
Lead time	Usually in Stock

Main
Color	Black
Product or Component Type	PDU
PDU Type	Metered
Cord length	5.97 ft (1.82 m)
Number of cables	1
Provided Equipment	Installation guide Rack Mounting brackets Serial configuration cable Safety guide

Complementary
Input Voltage	208 V 3 phase
Height	72.008 in (1829 mm)
Width	2.2 in (56 mm)
Output Voltage	208 V
Depth	2.008 in (51 mm)
Net Weight	22.5 lb(US) (10.2 kg)
Mounting Location	Side
Mounting preference	No preference
Input Plug Type	IEC 60309 60 A 3P+PE
Mounting Mode	Rack-mounted
Rack units	0U
Mounting position	Vertical
Line Rated Current	48 A
Max line current	48 A
Input current limits	60 A
Load Capacity	17300 VA
Input Frequency	50/60 Hz
Outlet type and quantity	30 IEC 60320 C13

Environment
Product Certifications	cUL Listed UL Listed VCCI Class A
Standards	EN 55022 Class A EN 55024 EN 61000-3-2 EN 61000-3-3 FCC Part 15 class A
Ambient air temperature for operation	23…140 °F (-5…60 °C)
Relative Humidity	5…95 %
Operating altitude	0…10000 ft
Ambient Air Temperature for Storage	-13…149 °F (-25…65 °C)
Storage Relative Humidity	5…95 %
Storage altitude	0…50000 ft (0…15240 m)

Ordering and shipping details
GTIN	731304289913
Country of origin	IN

Packing Units
Unit Type of Package 1	PCE
Nbr. of units in pkg.	1
Package 1 Height	84.6 in (214.9 cm)
Package 1 Width	4.4 in (11.2 cm)
Package 1 Length	8.7 in (22.1 cm)
Package weight(Lbs)	30.97 lb(US) (14.05 kg)

Contractual warranty
Warranty	2 years repair or replace

Specs

Videos

Additional information

Weight	30 lbs
Dimensions	84 × 8.12 × 4.04 in
