Description
APC/Schneider Electric APC Smart-UPS X 3000VA Rack/Tower LCD 10 PN SMX3000LV
APC Smart-UPS X, Line Interactive, 3kVA, Rack/tower convertible 4U, 100V-127V, 6x 5-15R+3x 5-20R+1x L5-30R NEMA,SmartSlot,Extended runtime,Short depth
APC Smart-UPS X 3000VA Rack/Tower LCD 100-127V
APC/Schneider Electric APC Smart-UPS X 3000VA Rack/Tower LCD 10 PN SMX3000LV is designed for IT managers or network administrators to maintain business uptime, data transfer and continuity during prolonged power outages. The 2880VA line interactive 4U rack/tower UPS provides pure sine wave power to support critical electronics during power disruptions. The SMX comes with NEMA L5-30P input, 6x NEMA 5-15R, 3x NEMA 5-20R and 1x NEMA L5-30R outlets. The UPS has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. This uninterrupted power supply can connect to EcoStruxure IT or third-party centralized management platforms. The SMX UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. This is compatible with dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications. The Smart-UPS comes with a pair of tower-mounting stabilizing feet and rack-mounting brackets. The 3 switchable outlet groups allow more granular management of the power supplied to your devices. The Emergency Power Off feature enables the UPS to remotely shutdown during emergencies.
Specifications
Overview
| Presentation |
Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices. |
| Lead time |
Usually Ships within 2 Weeks |
Main
|
|
|
|
|
|
| Product or Component Type |
Uninterruptible power supply (UPS) |
Complementary
| Communication port type |
SmartSlot |
| Mounting mode |
Tower |
| UPS connectivity |
Serial port
USB port
Available expansion slot |
| Battery Size |
Lead-acid internal included |
Batteries & Runtime
| Run Time |
View Runtime Graph |
| Efficiency |
View Efficiency Graph |
| Battery Type |
Lead-Acid battery |
| Extendable Run Time |
1 |
| Included Battery Modules |
0 |
| Battery Slots Empty |
0 |
| Typical recharge time |
3 h |
| RBC Quantity |
1 |
| Battery life |
3…5 year(s) |
| Replacement battery |
APCRBC143
|
| Battery Charge Power (Watts) |
245 W rated |
General
| Provided equipment |
CD with software
Documentation CD
Installation guide
Rack mounting hardware
Rack Mounting brackets
Rack Mounting support rails
Removable support feet
Smart UPS signalling RS-232 cable
USB cable |
| Number of power module |
0 |
| Number of power module filled slots |
0 |
| Number of power module free slots |
0 |
| product web sub-family |
Extended run |
| Redundant |
No |
Physical
| Number of rack unit |
4U |
| Cable length |
8 ft (2.4 m) |
| Number of cables |
1 |
| color |
Black |
| Height |
17.008 in (432 mm) |
| Width |
7.008 in (178 mm) |
| Depth |
19.02 in (483 mm) |
| Net Weight |
85.19 lb(US) (38.64 kg) |
| Mounting Location |
Front |
| Mounting preference |
Lower |
| Mounting Mode |
Rack-mounted |
| Two post mountable |
1 |
| USB compatible |
Yes |
Input
| Main Input Voltage |
120 V AC |
| Other Input Voltage |
100 V
110 V
127 V |
| Input Connection Type |
NEMA L5-30P |
| Efficiency at full load |
70…153 V |
| Input Frequency |
50/60 Hz +/- 3 Hz auto-sensing |
Output
| Main Output Voltage |
120 V AC 1 phase |
| Other Output Voltage |
100 V
110 V
127 V |
| Kw Rating |
2700 W |
| Rated power in VA |
2880 VA |
| output connection type |
6 NEMA 5-15R
3 NEMA 5-20R
1 NEMA L5-30R |
| Harmonic distortion |
Less than 5% |
| Maximum configurable power in VA |
2880 VA |
| Max Configurable Power (Watts) |
2700 W |
| Transfer Time |
2-4 ms
4ms typical : 8ms maximum |
| Topology |
Line Interactive |
| Waveform Type |
Sine wave |
| Output frequency |
50/60 Hz +/- 3 Hz sync to mains |
Conformance
| Product Certifications |
BSMI
CSA
NOM
TÜV
VCCI Class A |
| Equipment protection policy |
Lifetime : $150000 |
Environmental
| Acoustic level |
55 dBA |
| Heat dissipation |
276 Btu/h |
| Operating altitude |
0…10000 ft |
| Ambient air temperature for operation |
32…104 °F (0…40 °C) |
| Ambient Air Temperature for Storage |
5…113 °F (-15…45 °C) |
| Storage altitude |
0…50000 ft (0…15240 m) |
| Relative Humidity |
0…95 % |
| Storage Relative Humidity |
0…95 % |
Communications & Management
| Control panel |
Multi-function LCD status and control console |
| Emergency Power Off (EPO) |
Yes |
| Free slots |
1 |
| Control panel |
LED status display with on line : on battery : replace battery and overload indicators |
| Alarm |
Alarm when on battery : distinctive low battery alarm : configurable delays |
Surge Protection and Filtering
| Surge energy rating |
540 J |
| Filtering |
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : m |
Ordering and shipping details
| Category |
11309 – APC RESALE PRODUCTS |
| GTIN |
731304292647 |
| Returnability |
No |
| Country of origin |
PH |
Packing Units
| Unit Type of Package 1 |
PCE |
| Nbr. of units in pkg. |
1 |
| Package 1 Height |
13.0 in (33 cm) |
| Package 1 Width |
24.9 in (63.3 cm) |
| Package 1 Length |
23.07 in (58.6 cm) |
| Package weight(Lbs) |
105.23 lb(US) (47.73 kg) |
| Pallet unit layers |
2 |
| Pallet layers |
4 |
Contractual warranty
| Warranty |
3 years repair or replace (excluding battery) and 2 years for battery, optional on-site warranties available, optional extended warranties available |
