APC/Schneider Electric APC Smart-UPS RT Tower Isolation Step-Down Transformer PN SURT003

$1,765.00

Offers isolation and step-down conversion

Enhances flexibility by converting high voltage (208V) input to low voltage (120V) output

Suitable for deployment in offices and data centers

Provides a compact space-saving solution

Equipped with an LCD display for easy monitoring and management

APC Smart-UPS RT Tower Isolation Step-Down Transformer

SKU: SURT003 Category: APC Uninterruptible Power Supplies Brand: APC/Schneider Electric

Description

APC/Schneider Electric APC Smart-UPS RT Tower Isolation Step-Down Transformer PN SURT003

Name: APC/Schneider Electric APC Smart-UPS RT Tower Isolation Step-Down Transformer PN SURT003
Brand: APC/Schneider Electric
SKU: SURT003
Availability: InStock

APC Smart-UPS RT Tower Isolation/Step-Down Transformer

APC/Schneider Electric APC Smart-UPS RT Tower Isolation Step-Down Transformer PN SURT003 supports a load capacity of 4800VA. It features a 3U rack-mount design and is rack mountable with kit. It includes an installation guide and user manual.

Specifications

Overview
Lead time	Special Order – Call for Quoted Lead Times

Main
Main Input Voltage	208 V 240 V
Product or Component Type	Transformer
Main Output Voltage	120 V 208 V
Other Output Voltage	240 V
Input Connection Type	NEMA L6-30P
Number of rack unit	3U
Cable length	3.0 ft (0.9 m)
Number of cables	1
Provided Equipment	Installation guide User Manual

Physical
Color	Black
Height	17.008 in (432 mm)
Width	5.1 in (130 mm)
Depth	26.0 in (660 mm)
Net Weight	125.27 lb(US) (56.82 kg)
Mounting Location	Front
Mounting preference	Lower
Mounting Mode	Rack-mounted with kit
USB compatible	No
Mounting position	Vertical

Input
Acceptable Input Voltage	180…264 V
Input current limits	30 A
Load Capacity	4800 VA
Input Frequency	50/60 Hz

Output
Maximum Total Current Draw per Phase	30 A
Protection Type	Circuit breaker
Number of power socket outlets	8 NEMA 5-20R 2 NEMA L6-20R 1 NEMA L6-30R 1 NEMA L14-30R

Environmental
Ambient air temperature for operation	32…104 °F (0…40 °C)
Relative Humidity	0…95 %
Operating altitude	0…10000 ft
Ambient Air Temperature for Storage	-13…149 °F (-25…65 °C)
Storage Relative Humidity	0…95 %
Storage altitude	0…50000 ft (0…15240 m)

Ordering and shipping details
GTIN	731304217800

Packing Units
Unit Type of Package 1	PCE
Nbr. of units in pkg.	1
Package 1 Height	13.7 in (34.7 cm)
Package 1 Width	38.6 in (98 cm)
Package 1 Length	23.7 in (60.3 cm)
Package weight(Lbs)	140.30 lb(US) (63.64 kg)
SCC14	10731304217807

Contractual warranty
Warranty	2 years repair or replace

Additional information

Weight	138 lbs
Dimensions	35.3 × 23 × 35.3 in
