APC/Schneider Electric APC SMART-UPS RT 3000VA 120V PN SURTA3000XL

APC/Schneider Electric APC SMART-UPS RT 3000VA 120V PN SURTA3000XL

APC/Schneider Electric APC SMART-UPS RT 3000VA 120V PN SURTA3000XL

$5,520.00

Discontinued on:1 Oct 2025
To be end-of-service on:1 Oct 2027

APC SMART-UPS RT 3000VA 120V

SKU: SURTA3000XL Category: Brand:

Description

APC/Schneider Electric APC SMART-UPS RT 3000VA 120V PN SURTA3000XL

APC SMART-UPS RT 3000VA 120V

Specifications

Overview
Presentation High density, double-conversion on-line power protection with scalable runtime.
Lead time Usually in Stock
Main
Run time for load

W

Min-max: 210-2100 W
12min 7s
Max. Capacity Used

100 %
Main Input Voltage 120 V AC 1 phase
Product or component type Uninterruptible power supply (UPS)
Main Output Voltage 120 V AC 1 phase
Rated power in W 2100 W
Rated power in VA 3000 VA
Input Connection Type NEMA L5-30P
output connection type 6 NEMA 5-15R
2 NEMA 5-20R
Number of rack unit 3U
Cable length 2.4 m
Number of cables 1
Provided equipment CD with software
Smart UPS signalling RS-232 cable
User manual
Range of product Smart-UPS On-Line
Complementary
Battery type Lead-acid internal included
UPS connectivity Serial port
USB port
Mounting mode Tower
Batteries & Runtime
Run Time

Efficiency

Battery type Lead-acid battery
Extended runtime 1
Number of battery filled slots 2
Battery recharge time 2.5 h
Number of battery replacement quantity 1
Battery life 3…5 year(s)
Replacement battery

Battery charger power 339 W rated
General
Number of power module filled slots 0
Number of power module free slots 0
Redundant No
UPS type Double conversion online
Physical
Colour Black
Height 432 mm
Width 130 mm
Depth 660 mm
Net weight 54.55 kg
Mounting location Front
Mounting preference Lower
Mounting mode Not rack-mountable
Two post mountable 0
USB compatible No
Input
Input voltage limits 90…150 V
Network frequency 50/60 Hz +/- 5 Hz auto-sensing
Output
Bypass type Internal bypass (automatic and manual)
Crest factor 3 : 1
Harmonic distortion Less than 3 %
Maximum configurable power in VA 3000 VA
Maximum configurable power in W 2100 W
Wave type Sine wave
Output frequency 50/60 Hz +/- 3 Hz user adjustable +/- 0.1 Hz sync to mains
Conformance
Product certifications CSA
Environmental
Acoustic level 55 dBA
Heat dissipation 655 Btu/h
Operating altitude 0…10000 ft
Ambient air temperature for operation 0…40 °C
Ambient air temperature for storage -15…45 °C
Storage altitude 0…15240 m
IP degree of protection IP20
Relative humidity 0…95 % non-condensing
Storage Relative Humidity 0…95 % non-condensing
Communications & Management
Emergency power off Yes
Free slots 1
Alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering
Surge energy rate 480 J
Noise suppression Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 34.7 cm
Package 1 Width 98 cm
Package 1 Length 60.3 cm
Package 1 Weight 63.64 kg
Contractual warranty
Warranty 2 years repair or replace

Additional information

Weight 150 lbs
Dimensions 32 × 20 × 11.5 in
