APC/Schneider Electric APC Smart-UPS RT 20kVA RM 208V PN SURT20KRMXLT

$33,345.00

20kVA power capacity for high-demand environments

True double-conversion on-line power protection

Rackmount design fits 12U space for flexible installation

LCD display for easy monitoring and management

APC Smart-UPS RT 20kVA RM 208V

SKU: SURT20KRMXLT Category: APC Uninterruptible Power Supplies Brand: APC/Schneider Electric

Description

APC/Schneider Electric APC Smart-UPS RT 20kVA RM 208V PN SURT20KRMXLT

Name: APC/Schneider Electric APC Smart-UPS RT 20kVA RM 208V PN SURT20KRMXLT
Brand: APC/Schneider Electric
SKU: SURT20KRMXLT
Availability: InStock

APC Smart-UPS RT 20kVA RM 208V

APC/Schneider Electric APC Smart-UPS RT 20kVA RM 208V PN SURT20KRMXLT is an online UPS with a power rating of 20kVA and output power capacity of 16000 watts. It includes multiple output connections such as NEMA L6-20R and NEMA L6-30R. This model is includes a lead-acid battery and is rack-mountable. It features a double conversion online topology, sine wave waveform type, and built-in bypass.

Specifications

Overview
Lead time	Usually Ships within 2 Weeks

Main
Run time for load W Min-max: 1600-16000 W	4min 53s
Max. Capacity Used	100 %
Main Input Voltage	208 V AC 1 phase 240 V AC 1 phase
Product or Component Type	Uninterruptible power supply (UPS)
Other Input Voltage	240 V
Main Output Voltage	208 V AC 1 phase 240 V AC 1 phase
Other Output Voltage	240 V
Kw Rating	16000 W
Rated power in VA	20000 VA
output connection type	4 NEMA L6-20R 2 NEMA L6-30R
Output connector type	Hard Wire 3-wire (2PH + G) for 1 zone(s)
Number of rack unit	12U
Provided equipment	CD with software Rack Mounting support rails Smart UPS signalling RS-232 cable User Manual Web/SNMP Management Card
Range of Product	Smart-UPS On-Line

Complementary
Battery Size	Lead-acid internal included
UPS connectivity	Serial port Pre-installed network management card 3
Mounting mode	Rack-mounted with included kit

Batteries & Runtime
Run Time
Efficiency
Battery Type	Lead-Acid battery
Battery Voltage	+/-192 V (split battery referenced to neutral)
Extendable Run Time	1
Included Battery Modules	4
Battery Slots Empty	0
Typical recharge time	2 h
RBC Quantity	4
Battery life	3…5 year(s)
Replacement battery
End of Discharge Battery Voltage	+/-154 V
Battery Charge Power (Watts)	1910 W rated

General
Number of power module filled slots	0
Number of power module free slots	0
Redundant	No
Topology	Double Conversion Online

Physical
color	Black
Height	21.0 in (533 mm)
Width	17.008 in (432 mm)
Depth	30.4 in (773 mm)
Net Weight	546.15 lb(US) (247.73 kg)
Mounting Location	Front
Mounting preference	Lower
Mounting Mode	Rack-mounted
Two post mountable	0
USB compatible	No

Input
Maximum Input Current per Phase	114 A
Input Total Harmonic Distortion	Less than 5% for full load
Input Power Factor at Full Load	0.99
Switching current capacity	125 A
Efficiency at full load	160…280 V
Number of input connectors	1 Hard Wire 3-wire (2PH + G)
Input Frequency	40 – 70 Hz auto-sensing

Output
Bypass type	Built-in Static Bypass Internal Bypass (Automatic and Manual) Optional External Bypass
Crest factor	3 : 1
Harmonic distortion	Less than 5%
Maximum configurable power in VA	20000 VA
Max Configurable Power (Watts)	16000 W
Overload Operation	60 seconds @ 125% and 30 seconds @ 150%
Waveform Type	Sine wave
Efficiency at full load	93 % in battery operation)
Output frequency	50/60 Hz +/- 3 Hz user adjustable +/- 0.1 sync to mains
Additional information	Configurable for 208 or 240 nominal output voltage

Conformance
Product Certifications	UL 1778

Environmental
Acoustic level	59 dBA
Heat dissipation	4320 Btu/h
Operating altitude	0…10000 ft
Ambient air temperature for operation	32…104 °F (0…40 °C)
Ambient Air Temperature for Storage	5…113 °F (-15…45 °C)
Storage altitude	0…50000 ft (0…15240 m)
IP degree of protection	IP20
Relative Humidity	0…95 % non-condensing
Storage Relative Humidity	0…95 % non-condensing

Communications & Management
Emergency Power Off (EPO)	Yes
Free slots	0
Pre-Installed SmartSlot™ Cards	Network management card 2 with environmental monitoring

Surge Protection and Filtering
Filtering	Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : m

Ordering and shipping details
Category	80230-IG SEBA TO SEUSA
Discount Schedule	BMS1
GTIN	731304266358
Returnability	No
Country of origin	PH

Packing Units
Unit Type of Package 1	PCE
Nbr. of units in pkg.	1
Package 1 Height	39.0 in (99 cm)
Package 1 Width	39.5 in (100.3 cm)
Package 1 Length	24.02 in (61 cm)
Package weight(Lbs)	692.85 lb(US) (314.27 kg)

Contractual warranty
Warranty	2 years repair or replace

Additional information

Weight	610 lbs
Dimensions	39 × 24 × 38 in
