APC/Schneider Electric APC SMART-UPS 5000VA 208V RACKMOUNT TOWE PN SUA5000RMT5U

$8,165.00

“Intelligent and efficient network power protection from entry level to scalable runtime. “

“Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.”

“Provides remote management of the UPS over the network.”

“LED status indicators Quickly understand unit and power status with visual indicators”

APC SMART-UPS 5000VA 208V RACKMOUNT TOWE

SKU: SUA5000RMT5U Category: APC Uninterruptible Power Supplies Brand: APC/Schneider Electric

Description

APC/Schneider Electric APC SMART-UPS 5000VA 208V RACKMOUNT TOWE PN SUA5000RMT5U

Name: APC/Schneider Electric APC SMART-UPS 5000VA 208V RACKMOUNT TOWE PN SUA5000RMT5U
Brand: APC/Schneider Electric
SKU: SUA5000RMT5U
Availability: InStock

APC Smart-UPS 5000VA 208V Rackmount/Tower

APC/Schneider Electric APC SMART-UPS 5000VA 208V RACKMOUNT TOWE PN SUA5000RMT5U is a rackmount or tower UPS with a power rating of 5000VA and 4000 watts. It supports 208V input and output, and includes multiple output connections such as 2 NEMA L6-20R and 2 NEMA L6-30R. The UPS uses lead-acid batteries and features a SmartSlot for additional management options.

Specifications

Overview
Presentation	Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
Lead time	Usually Ships within 3 Weeks

Main
Run time for load W Min-max: 400-4000 W	9min 21s
Max. Capacity Used	100 %
Product or Component Type	Uninterruptible power supply (UPS)

Complementary
Communication port type	SmartSlot
Mounting mode	Rack-mounted with included kit
UPS connectivity	Serial port USB port Available expansion slot
Battery Size	Lead-acid internal included

Batteries & Runtime
Run Time
Efficiency
Battery Type	Lead-Acid battery
Extendable Run Time	0
Included Battery Modules	0
Battery Slots Empty	0
Typical recharge time	3 h
RBC Quantity	2
Battery life	3…5 year(s)
Replacement battery
Battery Charge Power (Watts)	542 W rated

General
Provided equipment	CD with software Rack Mounting support rails Smart UPS signalling RS-232 cable User Manual Web/SNMP Management Card
Number of power module	0
Number of power module filled slots	0
Number of power module free slots	0
Redundant	No

Physical
Number of rack unit	5U
Cable length	8 ft (2.4 m)
Number of cables	1
color	Black
Height	8.7 in (222 mm)
Width	19.02 in (483 mm)
Depth	26.0 in (660 mm)
Net Weight	215.46 lb(US) (97.73 kg)
Mounting Location	Front
Mounting preference	Lower
Mounting Mode	Rack-mounted
Two post mountable	0
USB compatible	No

Input
Main Input Voltage	208 V AC 1 phase
Input Connection Type	NEMA L6-30P
Efficiency at full load	131…268 V adjustable 141…255 V
Input Frequency	50/60 Hz +/- 5 Hz manual switch

Output
Main Output Voltage	208 V AC 1 phase
Kw Rating	4000 W
Rated power in VA	5000 VA
output connection type	2 NEMA L6-20R 2 NEMA L6-30R
Harmonic distortion	Less than 5 % at full load
Maximum configurable power in VA	5000 VA
Max Configurable Power (Watts)	4000 W
Transfer Time	2ms typical : 4ms maximum
Topology	Line Interactive
Waveform Type	Sine wave
Output frequency	47…53 Hz for 50 Hz nominal sync to mains 57…63 Hz for 60 Hz nominal sync to mains

Conformance
Product Certifications	CSA
Equipment protection policy	Lifetime : $150000

Environmental
Acoustic level	53 dBA
Heat dissipation	344 Btu/h
Operating altitude	0…10000 ft
Ambient air temperature for operation	32…113 °F (0…45 °C)
Ambient Air Temperature for Storage	23…131 °F (-5…55 °C)
Storage altitude	0…50000 ft (0…15240 m)
Relative Humidity	0…95 %
Storage Relative Humidity	0…95 %

Communications & Management
Control panel	LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators
Emergency Power Off (EPO)	Optional
Free slots	0
Pre-Installed SmartSlot™ Cards	Network management card
Alarm	Alarm when on battery : distinctive low battery alarm : configurable delays

Surge Protection and Filtering
Surge energy rating	480 J
Filtering	Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : m

Ordering and shipping details
Category	11309 – APC RESALE PRODUCTS
GTIN	731304255338
Returnability	No
Country of origin	PH

Packing Units
Unit Type of Package 1	PCE
Nbr. of units in pkg.	1
Package 1 Height	25.0 in (63.5 cm)
Package 1 Width	30.0 in (76.2 cm)
Package 1 Length	24.02 in (61 cm)
Package weight(Lbs)	235.50 lb(US) (106.82 kg)

Contractual warranty
Warranty	2 years repair or replace

Additional information

Weight	295 lbs
Dimensions	39 × 24.5 × 20 in
