Description
APC/Schneider Electric APC Smart-UPS 2200VA LCD RM 2U120V US PN SMT2200RMUS
APC Smart-UPS, Line Interactive, 2200VA, Rackmount 2U, 120V, 6x NEMA 5-15R+2x NEMA 5-20R outlets, SmartSlot, AVR, LCD [TAA]
APC/Schneider Electric APC Smart-UPS 2200VA LCD RM 2U120V US PN SMT2200RMUS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 1920VA line interactive 2U rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with NEMA 5-20P input, 6 NEMA 5-15R and 2 NEMA 5-20R outlets. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMT UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. It is compatible with a dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications.
Specifications
Overview
| Lead time |
Usually Ships within 3 Weeks |
Main
|
|
|
|
|
|
| Product or Component Type |
Uninterruptible power supply (UPS) |
Complementary
| Communication port type |
SmartSlot |
| Mounting mode |
Rack-mounted with included kit |
| UPS connectivity |
Serial port
USB port
Available expansion slot |
| Battery Size |
Lead-acid internal included |
Batteries & Runtime
| Run Time |
View Runtime Graph |
| Efficiency |
View Efficiency Graph |
| Battery Type |
Lead-Acid battery |
| Extendable Run Time |
0 |
| Included Battery Modules |
0 |
| Battery Slots Empty |
0 |
| Typical recharge time |
3 h |
| RBC Quantity |
1 |
| Battery life |
3…5 year(s) |
| Replacement battery |
RBC43
|
| Battery Charge Power (Watts) |
164 W rated |
General
| Provided equipment |
CD with software
Documentation CD
Rack Mounting brackets
Rack Mounting support rails
Smart UPS signalling RS-232 cable
USB cable |
| Number of power module |
0 |
| Number of power module filled slots |
0 |
| Number of power module free slots |
0 |
| product web sub-family |
TAA compliance |
| Redundant |
No |
Physical
| Number of rack unit |
2U |
| Cable length |
8 ft (2.4 m) |
| Number of cables |
1 |
| color |
Black |
| Height |
3.4 in (86 mm) |
| Width |
18.9 in (480 mm) |
| Depth |
26.9 in (683 mm) |
| Net Weight |
93.28 lb(US) (42.31 kg) |
| Mounting Location |
Front |
| Mounting preference |
Lower |
| Mounting Mode |
Rack-mounted |
| Two post mountable |
0 |
| USB compatible |
Yes |
Input
| Main Input Voltage |
120 V AC 1 phase |
| Input Connection Type |
NEMA 5-20P |
| Efficiency at full load |
75…154 V adjustable
82…143 V |
| Input Frequency |
50/60 Hz +/- 3 Hz auto-sensing |
Output
| Main Output Voltage |
120 V AC 1 phase |
| Kw Rating |
1920 W |
| Rated power in VA |
1920 VA |
| output connection type |
6 NEMA 5-15R
2 NEMA 5-20R |
| Harmonic distortion |
Less than 5% |
| Maximum configurable power in VA |
2200 VA |
| Max Configurable Power (Watts) |
1980 W |
| Transfer Time |
4ms typical : 8ms maximum |
| Topology |
Line Interactive |
| Waveform Type |
Sine wave |
| Output frequency |
50/60 Hz +/- 3 Hz sync to mains |
Conformance
| Product Certifications |
CSA
TAA compliance |
| Equipment protection policy |
Lifetime : $150000 |
Environmental
| Acoustic level |
55 dBA |
| Heat dissipation |
215 Btu/h |
| Operating altitude |
0…10000 ft |
| Ambient air temperature for operation |
32…104 °F (0…40 °C) |
| Ambient Air Temperature for Storage |
5…113 °F (-15…45 °C) |
| Storage altitude |
0…50000 ft (0…15240 m) |
| Relative Humidity |
0…95 % |
| Storage Relative Humidity |
0…95 % |
Communications & Management
| Control panel |
Multi-function LCD status and control console |
| Emergency Power Off (EPO) |
Yes |
| Free slots |
1 |
| Control panel |
LED status display with on line : on battery : replace battery and overload indicators |
| Alarm |
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
Surge Protection and Filtering
| Surge energy rating |
530 J |
Ordering and shipping details
| GTIN |
731304305613 |
| Country of origin |
IN |
Packing Units
| Unit Type of Package 1 |
PCE |
| Nbr. of units in pkg. |
1 |
| Package 1 Height |
10.0 in (25.4 cm) |
| Package 1 Width |
38.6 in (98 cm) |
| Package 1 Length |
23.6 in (60 cm) |
| Package weight(Lbs) |
109.64 lb(US) (49.73 kg) |
Compliance
| Compliance |
TAA |
Contractual warranty
| Warranty |
3 years repair or replace (excluding battery) and 2 years for battery |
